Product Advantages
Weichai WP7 Engine – Meets China III/China IV Emission Standards
High Market Coverage – Leveraging a Wide Service Network
Tested in Extreme Environments – Operates in temperatures ranging from -35°C to 50°C and at altitudes up to 5000 meters
Fuel System: Three-stage filtration protection reduces fuel-related malfunctions
Intake System: Radial sealing multi-stage composite dust removal filtration
Optimized Fuel Efficiency – Directly connected to the engine air compressor
Equipped with a 7m³/min air compressor
Technical Specifications
|
Impact power(kW)
|
16
|
|
Hole Range(mm)
|
Ø41~80
|
|
Drill rod
|
T38/T45
|
|
Hole depth(mm)
|
0~6000
|
|
Deflection angle
|
Left 100°/right 15°
|
|
Air compressors
|
screw-type
|
|
Air compressor flow rate(m3/min)
|
3
|
|
Engine power/speed
|
92kW/2200rpm
|
|
Hydraulic flow rate(L/min)
|
150×2
|
|
Dust collector air volume(m3/min)
|
18Max
|
|
Crawling speed(km/h)
|
3.25/5.2
|
|
Gradeability
|
50%(30°)
|
|
Horizontal lifting height
|
6m
|
|
Vertical lifting height
|
2.5m
|
|
Vertical drilling depth
|
3.6m
|
|
The maximum distance between the vertical drilling rig and the track
|
3.5m
|
|
L×W×H(mm)
|
9800×2490×3100
|
|
Weight(kg)
|
12600
|
FAQ
1. What are the differences between this truck-mounted drilling rig and a tracked drilling rig?
It adopts a truck-mounted chassis design, enabling road travel and faster site relocation, suitable for multi-site rotation operations.
2. What are the drilling diameter and depth?
Drilling diameter φ41-80mm, single-hole drilling depth up to 6 meters.
3. What is the engine configuration?
Equipped with a Weichai WP7 engine, power 92kW, meeting National III/National IV emission standards, with high market coverage and a wide service network.
4. Can it work in extreme environments?
Yes, it has withstood extreme environmental testing, operating in a temperature range of -35°C to 50°C and at an altitude of 5000 meters.
5. What are the features of the fuel system?
Three-stage filtration protection reduces fuel-related failures; the intake system uses radial sealing multi-stage composite dust removal filtration.
6. How is it shipped overseas?
Shipped by 40-foot flatbed container or roll-on/roll-off ship, shipped as a whole truckload.
7. What is the delivery time?
Standard models are shipped 30-45 days after payment.
8. Are English materials and training provided?
English operation manuals and video tutorials are provided.
9. What is the air compressor configuration?
Configured with a 7m³/min air compressor to meet drilling operation needs.
10. What is the fuel efficiency?
The engine is directly coupled to the air compressor, optimizing fuel efficiency and reducing operating costs.
11. What are the applicable operating scenarios?
Earth excavation and blasting drilling operations in construction fields such as highways, railways, industrial parks, and urban construction.
12. Is maintenance convenient?
The vehicle chassis has a wide maintenance network, and spare parts are readily available.
13. What payment methods are supported?
T/T and letter of credit at sight are supported.
