Rotary Blasthole Drill Rigs

Name: Rotary Blasthole Drill Rigs
Brand: PivotPro Africa
Price: 10000.00 CNY
Availability: InStock

Important Reminder

PIVOT specializes in providing customized mechanical solutions for industrial scenarios. Due to variations in product configurations, application scenarios, and cooperation scales, uniform pricing and inventory information are not publicly listed.

Whether you need detailed technical specifications, personalized solution design, or a precise cooperation quote, our engineering team will offer one-on-one professional support.

Contact us now to efficiently align your requirements and initiate the customized cooperation process.

Rotary blasthole drill rigs are large-scale, track- or truck-mounted machines that use a rotary motion and downward pressure to bore large-diameter holes，These holes are then charged with explosives to break up the rock for easier excavation.

Inquire Now

View Full Details

Rotary blasthole drill rigs are large-scale, track- or truck-mounted machines that use a rotary motion and downward pressure to bore large-diameter holes,These holes are then charged with explosives to break up the rock for easier excavation.

Our rotary blasthole drill rigs are engineered for surface drilling across industries including:

Mining
Quarrying
Construction
Civil Engineering
Dimension Stone Extraction

They offer a hole diameter range of φ76–102 mm to φ76–115 mm, accommodating a broad spectrum of drilling needs.In real-world applications, a single operation can drill a 6-meter hole with speed and precision, significantly enhancing blasting efficiency and reducing cycle times.

Technical Specifications

Impact power(kW)	18/21(optional)
Hole Range(mm)	φ76～102/φ76～115
Drill rod	T38,T45 / T45,T51
Hole depth(mm)	0~6000
Deflection angle	L/R 20°
Air compressors	screw-type
Air compressor flow rate(m3/min)	6
Engine power/speed	127kW/2200rpm
Hydraulic flow rate(L/min)	220×2
Dust collector air volume(m3/min)	24max
Crawling speed(km/h)	2.9/4.3
Gradeability	50%(30°)
L×W×H(mm)	14100×2800×2977
Weight(kg)	21000

Key Features and Technical Advantages

360° Rotating Platform: Full-rotation platform provides a wide working range and exceptional maneuverability in rugged terrain.
Adopting international brand supporting wheels, guide wheels and sprockets, it has excellent climbing ability and stability even on uneven ground.
Load-sensitive hydraulic system reduces energy loss and minimizes fuel consumption,Efficient power distribution ensures longer operating cycles with less downtime
Cabin equipped with heating and cooling air conditioning for all-season use,Spacious, safe design allows easy access for daily inspection, maintenance, and repair
Customization and accessories can be added according to special needs, such as water mist dust removal system, cutting device for drilling soft rocks such as sandstone and shale, deflection function, etc.

Why Choose Our Rotary Blasthole Drill Rigs?

Our rigs combine cutting-edge technology, proven mechanical reliability, and field-tested components from leading global manufacturers. The result is a powerful, dependable machine that boosts operational efficiency and keeps your project on schedule.

Get in touch today to learn how our rotary blasthole drill rigs can drive productivity and safety at your job site. Request a quote or speak with a specialist now.
