Core Advantages
Mobility and Adaptability: Equipped with a 360° rotating platform and tracked walking mechanism, offering excellent mobility; robust structural design suitable for frequent site relocation and continuous operation.
Operating Performance: Integrated hydraulic system (domestically leading design); employs energy-saving technologies compliant with certified manufacturing standards.
Operating Environment: Temperature-controlled cab with air conditioning; open layout for easy maintenance and operation.
Technical Specifications
|
Impact power(kW)
|
18/21(optional)
|
|
Hole Range(mm)
|
φ76～102/φ76～115
|
|
Drill rod
|
T38,T45 / T45,T51
|
|
Hole depth(mm)
|
0~6000
|
|
Deflection angle
|
L/R 20°
|
|
Air compressors
|
screw-type
|
|
Air compressor flow rate(m3/min)
|
6
|
|
Engine power/speed
|
127kW/2200rpm
|
|
Hydraulic flow rate(L/min)
|
220×2
|
|
Dust collector air volume(m3/min)
|
24max
|
|
Crawling speed(km/h)
|
2.9/4.3
|
|
Gradeability
|
50%(30°)
|
|
L×W×H(mm)
|
14100×2800×2977
|
|
Weight(kg)
|
21000
|
FAQ
1. What types of projects is this rock drill/piling rig suitable for?
Suitable for anchoring, anchor reinforcement, foundation pit reinforcement, tunnel support, and other operations in mining, quarrying, construction, civil engineering, stone processing, mining, dams, railways, highways, and other fields.
2. What are the drilling diameter and depth?
Drilling diameter φ76-115mm (some models φ76-180mm), drilling depth 0-6000mm (some models 0-10000mm).
3. What is the impact power?
Impact power 18-21kW optional, powerful.
4. What are the features of the hydraulic system?
Integrated hydraulic system (domestically leading design), using energy-saving technology that meets certified manufacturing standards.
5. What are the features of the rotary platform?
Equipped with a 360° rotary platform and crawler walking mechanism, providing good mobility and suitable for frequent site relocation and continuous operation.
6. How to ship overseas?
Shipped entirely by sea in 40-foot flat rack or open-top container.
7. Delivery time?
Standard models ship 30-45 days after payment.
8. Are English materials and training provided?
English operation manual and video tutorials are provided.
9. What are the unique advantages of the hydraulic piling drill rig (PVT-BS6)?
Lifting height 15-24 meters, 90° lateral drilling capability, plunger pump pressure 34MPa, built-in air compressor with independent operation capability.
10. What is the cab configuration?
Equipped with an air-conditioned, temperature-controlled cab; open layout for easy maintenance and operation.
11. Can it work in extreme environments?
Yes, adaptable to altitudes up to 5000 meters and temperatures ranging from -35°C to +50°C.
12. What optional configurations are available?
A dust suppression system is optional to meet cleaning operation requirements.
13. How is after-sales service provided overseas?
One-year warranty, genuine parts supply, and online technical support are provided.
14. What payment methods are supported?
T/T and letter of credit at sight are supported.
